Wall Hung Frames

Wall Hung Frames

0.82m 1.0m 1.17m 0.4m
Wall Hung Frame Wall Hung WC Frame Wall Hung Frame WC / Bidet Frame

500(w) x 820(h) x 167-215(d)mm 500(w) x 1000(h) x 167-215(d)mm 500(w) x 1168(h) x 140-200(d)mm 400(w) x 400(h) x 170-335(d)mm
• Use with 600 or wider WC units • Rubber pipe mount to reduce noise
• Use for boxed in applications • Use for in-wall applications
• Air Gap inlet valve • Compatible With Vortex
• Air Gap inlet valve • Air Gap inlet valve
• Requires Adaptor Kit for furniture or Comfort Cistern
FB06288 FB06298 FB06289 FB06301

£348.00 £348.00 £348.00 £161.00
Can be used with Ellipse push plate Requires flush plate / button or Can be used with Ellipse push plate Allows wall hung WC pans to
or Square flush button contactless sensor or Square flush button be installed in slim depth
narrow units such as
FB06290 • Furniture Adaptor Kit Match or 500mm BTW Units

£59.50
Optional Furniture Adaptor Kit
when used in furniture installations

Boxed/Tiled In
Flushing Std. Depth Std. Depth Slim Depth Slim Depth Boxed/Tiled In Boxed/Tiled In
Solution 500 BTW Unit 600 BTW Unit 500 BTW Unit 600 BTW Unit With Worktop Full Height Full Height:
Slim Stud Wall
1.17m Wall Hung • •
Frame (FB06289)
1.0m Wall Hung • •
Frame (FB06298)
0.82m Wall Hung Use With Furniture Use With Furniture • •
Frame (FB06288) Adaptor Kit FB06290 Adaptor Kit FB06290
0.4m Wall Hung Use With Vortex, Apex Or Use With Vortex, Apex Or Use With Vortex, Apex Or Use With Vortex, Apex Or Use With Vortex, Apex Or
Frame* (FB06301) Comfort Height Cisterns Comfort Height Cisterns Comfort Height Cisterns Comfort Height Cisterns Comfort Height Cisterns

*Use with Comfort Height Cistern if a higher WC height is desired
158 Sanitaryware Add-ons All Tavistock Prices Are Valid From July 2024
